Specifications

1. Input: Type-C interface, 5V3A

2. Output :1.2V/3.7V (battery slot) /7.4V (adjustable pin) 700mA

3. Features:For charging:

a, one 3.6-3.7V/7.2-7.4V lithium-ion battery,

b,2 AA/AAA Ni-MH and Ni-Cd rechargeable batteries

c, identify the 3.7V/7.4V lithium-ion battery +/- pole

Core Positioning

This is a multi-functional battery charging adapter, it uses a Type-C input interface, converts to a 600mA current to charge lithium,-hydrogen and other types of batteries. The multi-functional charging feature of this product lies in the adjustable battery slot size, and there are adjustable pins on the side end. it applicable to battery blocks. It is mainly used to charge the batteries of household electronic products such as toys, remote controls, and even camera batteries.

Technical Highlights

1.Polarity Identification

The charger has a high-resolution ADC, which is recognized by the MCU, allowing for precise and quick judgment the battery's positive and negative polarity. There is no need to align the battery's positive and negative poles during charging.

2. Zero Voltage Activation

For that have been over-discharged causing the battery protection board to shut down and result in no voltage output, the charger will quickly output pulse signals to the battery to reactivate it This process is safe and reliable, causing no harm to the battery.

3. -△V Value

Considering the characteristics of nickel-cadmium and nickel-hydro batteries, the charger uses the detection of -△V as the main basis for judging these types of batteries when charging them.

Certification qualifications

International certification: Complies with UL 62368-1 (USA), IEC 62368 (EU safety standards.

Environmental protection certification: Complies with RoHS 3, REACH, and the EU Battery Directive (2023/2230EU).

Package

Product list: Micro cable *1, body *1

Single size (without packaging) :100*53*23mm

Single gross weight (including packaging) :90g

Carton size :51*51*51cm

Packing quantity: 114 pieces/box

Gross weight.:13kg

Payment & Lead time

T/T, 30% deposit, other balance must be paid before delivery.

20-25 days after receiving the deposit and confirming the details.

Delivery

We provide efficient and cost-effective logistics solutions:

To China and Hong Kong, Macao, Taiwan: SF 1-3 days

To areas: You can consult us for the most perfect and economical transportation plan:

For air: 3-7 days | For quick purchasing

Multimodal : 7-12 days  | Least cost, considering timeliness (most recommended)

Truck or rail: 15-30 days | For monthly purchase

Sea: 20-35 days | For quarterly purchase
